供应PAPST风机
请选择 型号/数量
商品详情
| 型号 | 外形尺寸 | 电压 | 风量 | 转速 | 功率 | 噪音 |
| 255 M | 25x25x8 | 5 VDC | 2,1 m3/h | 6000 min-1 | 0,20 W | 5 dB(A) |
| 255 N | 25x25x8 | 5 VDC | 3,2 m3/h | 9000 min-1 | 0,40 W | 15 dB(A) |
| 252 N | 25x25x8 | 12 VDC | 3,2 m3/h | 9000 min-1 | 0,50 W | 15 dB(A) |
| 255 H | 25x25x8 | 5 VDC | 4,5 m3/h | 1200 min-1 | 0,60 W | 28 dB(A) |
| 405 | 40x40x20 | 5 VDC | 10,0 m3/h | 6000 min-1 | 0,90 W | 18 dB(A) |
| 412 | 40x40x20 | 12 VDC | 10,0 m3/h | 6000 min-1 | 0,90 W | 18 dB(A) |
| 414 | 40x40x20 | 24 VDC | 10,0 m3/h | 6000 min-1 | 1,00 W | 18 dB(A) |
| 3312 | 92x92x32 | 12 VDC | 80,0 m3/h | 3000 min-1 | 2,40 W | 37 dB(A) |
| 3314 | 92x92x32 | 24 VDC | 80,0 m3/h | 3000 min-1 | 2,60 W | 37 dB(A) |
| 3318 | 92x92x32 | 48 VDC | 80,0 m3/h | 3000 min-1 | 2,70 W | 37 dB(A) |
| 3500 | 92x92x38 | 115 VAC | 73,0 m3/h | 2500 min-1 | 8,00 W | 35 dB(A) |
| 3506 | 92x92x38 | 115 VAC | 73,0 m3/h | 2600 min-1 | 8,00 W | 36 dB(A) |
| 3550 | 92x92x38 | 230 VAC | 67,0 m3/h | 2300 min-1 | 9,00 W | 32 dB(A) |
| 3556 | 92x92x38 | 230 VAC | 67,0 m3/h | 2400 min-1 | 9,00 W | 33 dB(A) |
| 3600 | 92x92x38 | 115 VAC | 89,0 m3/h | 3100 min-1 | 11,00 W | 41 dB(A) |
| 3606 | 92x92x38 | 115 VAC | 89,0 m3/h | 3200 min-1 | 11,00 W | 42 dB(A) |
| 3650 | 92x92x38 | 230 VAC | 75,0 m3/h | 2650 min-1 | 12,00 W | 36 dB(A) |
| 3656 | 92x92x38 | 230 VAC | 75,0 m3/h | 2700 min-1 | 12,00 W | 37 dB(A) |
| 3800 | 92x92x38 | 115 VAC | 54,0 m3/h | 1900 min-1 | 8,00 W | 26 dB(A) |
| 3806 | 92x92x38 | 115 VAC | 60,0 m3/h | 2150 min-1 | 8,00 W | 29 dB(A) |
| 3850 | 92x92x38 | 230 VAC | 49,0 m3/h | 1750 min-1 | 9,00 W | 24 dB(A) |
| 3856 | 92x92x38 | 230 VAC | 54,0 m3/h | 1950 min-1 | 9,00 W | 26 dB(A) |
| 3900 | 92x92x25 | 115 VAC | 70,0 m3/h | 3150 min-1 | 9,00 W | 40 dB(A) |
| 3906 | 92x92x25 | 115 VAC | 70,0 m3/h | 3150 min-1 | 9,00 W | 40 dB(A) |
| 3950 | 92x92x25 | 230 VAC | 59,0 m3/h | 2650 min-1 | 11,00 W | 35 dB(A) |
| 3956 | 92x92x25 | 230 VAC | 59,0 m3/h | 2650 min-1 | 11,00 W | 35 dB(A) |
| 4212 | 119x119x38 | 12 VDC | 165,0 m3/h | 3050 min-1 | 4,30 W | 45 dB(A) |
| 4214 | 119x119x38 | 24 VDC | 165,0 m3/h | 3050 min-1 | 4,30 W | 45 dB(A) |
| 4218 | 119x119x38 | 48 VDC | 165,0 m3/h | 3050 min-1 | 4,30 W | 45 dB(A) |
| 4312 | 119x119x32 | 12 VDC | 170,0 m3/h | 2800 min-1 | 5,00 W | 45 dB(A) |
| 4314 | 119x119x32 | 24 VDC | 170,0 m3/h | 2800 min-1 | 5,00 W | 45 dB(A) |
| 4318 | 119x119x32 | 48 VDC | 170,0 m3/h | 2800 min-1 | 5,00 W | 45 dB(A) |
| 5900 | 127x127x38 | 115 VAC | 206,0 m3/h | 3050 min-1 | 17,00 W | 46 dB(A) |
| 5908 | 127x127x38 | 115 VAC | 206,0 m3/h | 3100 min-1 | 17,00 W | 47 dB(A) |
| 5938 | 127x127x38 | 115 VAC | 162,0 m3/h | 2400 min-1 | 12,00 W | 39 dB(A) |
| 5950 | 127x127x38 | 230 VAC | 180,0 m3/h | 2700 min-1 | 18,00 W | 43 dB(A) |
| 5958 | 127x127x38 | 230 VAC | 180,0 m3/h | 2750 min-1 | 18,00 W | 44 dB(A) |
| 5988 | 127x127x38 | 230 VAC | 150,0 m3/h | 2250 min-1 | 13,00 W | 37 dB(A) |
| 6424 | 172x150x51 | 24 VDC | 410,0 m3/h | 3400 min-1 | 18,00 W | 57 dB(A) |
| 6448 | 172x150x51 | 48 VDC | 410,0 m3/h | 3400 min-1 | 17,00 W | 57 dB(A) |
| 8312 | 80x80x32 | 12 VDC | 54,0 m3/h | 3300 min-1 | 2,20 W | 36 dB(A) |
| 8314 | 80x80x32 | 24 VDC | 54,0 m3/h | 3300 min-1 | 2,50 W | 36 dB(A) |
| 8318 | 80x80x32 | 48 VDC | 54,0 m3/h | 3300 min-1 | 2,60 W | 36 dB(A) |
| 9900 | 119x119x25 | 115 VAC | 135,0 m3/h | 2850 min-1 | 12,00 W | 42 dB(A) |
| 9906 | 119x119x25 | 115 VAC | 135,0 m3/h | 2850 min-1 | 12,00 W | 42 dB(A) |
| 9950 | 119x119x25 | 230 VAC | 117,0 m3/h | 2450 min-1 | 14,00 W | 37 dB(A) |
| 9956 | 119x119x25 | 230 VAC | 117,0 m3/h | 2450 min-1 | 14,00 W | 37 dB(A) |
| 3212 JH-304 | 92x92x38 | 12 VDC | 146,0 m3/h | 6800 min-1 | 9,00 W | 55 dB(A) |
| 3212 JN | 92x92x38 | 12 VDC | 130,0 m3/h | 6000 min-1 | 7,50 W | 51 dB(A) |
| 3214 JH-306 | 92x92x38 | 24 VDC | 146,0 m3/h | 6800 min-1 | 9,00 W | 55 dB(A) |
| 3214 JN | 92x92x38 | 24 VDC | 130,0 m3/h | 6000 min-1 | 8,00 W | 51 dB(A) |
| 3218 JH-310 | 92x92x38 | 48 VDC | 146,0 m3/h | 6800 min-1 | 9,50 W | 55 dB(A) |
| 3218 JN | 92x92x38 | 48 VDC | 130,0 m3/h | 6000 min-1 | 7,00 W | 51 dB(A) |
| 3312 G | 92x92x32 | 12 VDC | 80,0 m3/h | 3000 min-1 | 2,40 W | 37 dB(A) |
| 3312 GL | 92x92x32 | 12 VDC | 56,0 m3/h | 2150 min-1 | 1,40 W | 29 dB(A) |
| 3312 GM | 92x92x32 | 12 VDC | 68,0 m3/h | 2600 min-1 | 1,70 W | 34 dB(A) |
| 3312 L | 92x92x32 | 12 VDC | 56,0 m3/h | 2150 min-1 | 1,40 W | 29 dB(A) |
| 3312 M | 92x92x32 | 12 VDC | 68,0 m3/h | 2600 min-1 | 1,70 W | 34 dB(A) |
| 3312-177 | 92x92x32 | 12 VDC | 93,0 m3/h | 3500 min-1 | 3,50 W | 43 dB(A) |
| 3314 G | 92x92x32 | 24 VDC | 80,0 m3/h | 3000 min-1 | 2,60 W | 37 dB(A) |
| 3314 H | 92x92x32 | 24 VDC | 107,0 m3/h | 4000 min-1 | 5,30 W | 47 dB(A) |
| 3314-140 | 92x92x32 | 24 VDC | 85,0 m3/h | 3200 min-1 | 3,00 W | 40 dB(A) |
| 3318 H | 92x92x32 | 48 VDC | 107,0 m3/h | 4000 min-1 | 4,30 W | 47 dB(A) |
| 3412 N | 92x92x25 | 12 VDC | 84,0 m3/h | 2700 min-1 | 2,20 W | 32 dB(A) |
| 3412 NG | 92x92x25 | 12 VDC | 84,0 m3/h | 2700 min-1 | 2,20 W | 32 dB(A) |
| 3412 NGH | 92x92x25 | 12 VDC | 94,0 m3/h | 3000 min-1 | 2,50 W | 36 dB(A) |
| 3412 NGHH | 92x92x25 | 12 VDC | 102,0 m3/h | 3250 min-1 | 3,20 W | 39 dB(A) |
| 3412 NGLE | 92x92x25 | 12 VDC | 61,0 m3/h | 1950 min-1 | 1,10 W | 23 dB(A) |
| 3412 NGME | 92x92x25 | 12 VDC | 72,0 m3/h | 2300 min-1 | 1,60 W | 28 dB(A) |
| 3412 NGMV | 92x92x25 | 12 VDC | 72,0 m3/h | 2300 min-1 | 2,00 W | 28 dB(A) |
| 3412 NGV | 92x92x25 | 12 VDC | 84,0 m3/h | 2700 min-1 | 2,50 W | 32 dB(A) |
| 3412 NH | 92x92x25 | 12 VDC | 94,0 m3/h | 3000 min-1 | 2,50 W | 36 dB(A) |
| 3412 NHH | 92x92x25 | 12 VDC | 102,0 m3/h | 3250 min-1 | 3,20 W | 39 dB(A) |
| 3412 NHH-379 | 92x92x25 | 12 VDC | 102,0 m3/h | 3250 min-1 | 2,70 W | 39 dB(A) |
| 3412 NLE | 92x92x25 | 12 VDC | 61,0 m3/h | 1950 min-1 | 0,80 W | 23 dB(A) |
| 3412 NME | 92x92x25 | 12 VDC | 72,0 m3/h | 2300 min-1 | 1,10 W | 28 dB(A) |
| 3414 N | 92x92x25 | 24 VDC | 84,0 m3/h | 2700 min-1 | 2,30 W | 32 dB(A) |
| 3414 NG | 92x92x25 | 24 VDC | 84,0 m3/h | 2700 min-1 | 2,30 W | 32 dB(A) |
| 3414 NGH | 92x92x25 | 24 VDC | 94,0 m3/h | 3000 min-1 | 3,00 W | 36 dB(A) |
| 3414 NGHH | 92x92x25 | 24 VDC | 102,0 m3/h | 3250 min-1 | 3,20 W | 39 dB(A) |
| 3414 NGHH-389 | 92x92x25 | 24 VDC | 102,0 m3/h | 3250 min-1 | 3,20 W | 39 dB(A) |
| 3414 NGL | 92x92x25 | 24 VDC | 61,0 m3/h | 1950 min-1 | 1,40 W | 23 dB(A) |
| 3414 NGM | 92x92x25 | 24 VDC | 72,0 m3/h | 2300 min-1 | 1,80 W | 28 dB(A) |
| 3414 NH | 92x92x25 | 24 VDC | 94,0 m3/h | 3000 min-1 | 3,00 W | 36 dB(A) |
| 3414 NHH | 92x92x25 | 24 VDC | 102,0 m3/h | 3250 min-1 | 3,20 W | 39 dB(A) |
| 3414 NHH-386 | 92x92x25 | 24 VDC | 102,0 m3/h | 3250 min-1 | 3,20 W | 39 dB(A) |
| 3414 NL | 92x92x25 | 24 VDC | 61,0 m3/h | 1950 min-1 | 1,40 W | 23 dB(A) |
| 3414 NM | 92x92x25 | 24 VDC | 72,0 m3/h | 2300 min-1 | 1,80 W | 28 dB(A) |
| 3900 L | 92x92x25 | 115 VAC | 39,0 m3/h | 1850 min-1 | 5,00 W | 27 dB(A) |
| 3900 M | 92x92x25 | 115 VAC | 53,0 m3/h | 2600 min-1 | 5,00 W | 34 dB(A) |
| 3906 L | 92x92x25 | 115 VAC | 39,0 m3/h | 1850 min-1 | 5,00 W | 27 dB(A) |
| 3906 M | 92x92x25 | 115 VAC | 53,0 m3/h | 2600 min-1 | 5,00 W | 34 dB(A) |
| 3950 L | 92x92x25 | 230 VAC | 31,0 m3/h | 1550 min-1 | 6,00 W | 24 dB(A) |
| 3950 M | 92x92x25 | 230 VAC | 45,0 m3/h | 2150 min-1 | 6,00 W | 29 dB(A) |
| 3956 L | 92x92x25 | 230 VAC | 31,0 m3/h | 1550 min-1 | 6,00 W | 24 dB(A) |
| 3956 M | 92x92x25 | 230 VAC | 45,0 m3/h | 2150 min-1 | 6,00 W | 29 dB(A) |
| 405 F | 40x40x10 | 5 VDC | 8,0 m3/h | 5400 min-1 | 0,70 W | 22 dB(A) |
| 405 FH | 40x40x10 | 5 VDC | 9,0 m3/h | 6000 min-1 | 0,90 W | 26 dB(A) |
| 4112 NHH | 119x119x38 | 12 VDC | 270,0 m3/h | 5000 min-1 | 15,50 W | 64 dB(A) |
| 4114 NHH | 119x119x38 | 24 VDC | 270,0 m3/h | 5000 min-1 | 15,50 W | 64 dB(A) |
| 4118 NHH | 119x119x38 | 48 VDC | 270,0 m3/h | 5000 min-1 | 15,50 W | 64 dB(A) |
| 412 F | 40x40x10 | 12 VDC | 8,0 m3/h | 5400 min-1 | 0,70 W | 22 dB(A) |
| 412 FH | 40x40x10 | 12 VDC | 9,0 m3/h | 6000 min-1 | 0,80 W | 26 dB(A) |
| 412 FM | 40x40x10 | 12 VDC | 6,0 m3/h | 4300 min-1 | 0,60 W | 16 dB(A) |
| 412 H | 40x40x20 | 12 VDC | 13,5 m3/h | 8100 min-1 | 1,60 W | 29 dB(A) |
| 412 J | 40x40x25 | 12 VDC | 19,0 m3/h | 10300 min-1 | 2,40 W | 39 dB(A) |
| 412 JH | 40x40x25 | 12 VDC | 22,0 m3/h | 11700 min-1 | 3,00 W | 43 dB(A) |
| 412 JHH | 40x40x25 | 12 VDC | 24,0 m3/h | 13000 min-1 | 3,30 W | 46 dB(A) |
| 414 F | 40x40x10 | 24 VDC | 8,0 m3/h | 5400 min-1 | 0,80 W | 22 dB(A) |
| 414 FH | 40x40x10 | 24 VDC | 9,0 m3/h | 6000 min-1 | 0,90 W | 26 dB(A) |
| 414 H | 40x40x20 | 24 VDC | 13,5 m3/h | 8100 min-1 | 1,60 W | 29 dB(A) |
| 414 J | 40x40x25 | 24 VDC | 19,0 m3/h | 10300 min-1 | 2,40 W | 39 dB(A) |
| 414 JH | 40x40x25 | 24 VDC | 22,0 m3/h | 11700 min-1 | 3,00 W | 43 dB(A) |
| 414 JHH | 40x40x25 | 24 VDC | 24,0 m3/h | 13000 min-1 | 3,60 W | 46 dB(A) |
| 4182 NGX | 119x119x38 | 12 VDC | 160,0 m3/h | 2800 min-1 | 3,50 W | 44 dB(A) |
| 4182 NX | 119x119x38 | 12 VDC | 180,0 m3/h | 3200 min-1 | 4,50 W | 49 dB(A) |
| 4182 NXH | 119x119x38 | 12 VDC | 237,0 m3/h | 4400 min-1 | 11,00 W | 59 dB(A) |
| 4184 NGX | 119x119x38 | 24 VDC | 160,0 m3/h | 2800 min-1 | 3,50 W | 44 dB(A) |
| 4184 NX | 119x119x38 | 24 VDC | 180,0 m3/h | 3200 min-1 | 4,50 W | 49 dB(A) |
| 4184 NXH | 119x119x38 | 24 VDC | 237,0 m3/h | 4400 min-1 | 11,00 W | 59 dB(A) |
| 4184 NXHH | 119x119x38 | 24 VDC | 250,0 m3/h | 4900 min-1 | 12,20 W | 60 dB(A) |
| 4188 NXM | 119x119x38 | 48 VDC | 160,0 m3/h | 2800 min-1 | 3,50 W | 44 dB(A) |
| 4212 GM | 119x119x38 | 12 VDC | 127,0 m3/h | 2350 min-1 | 2,20 W | 38 dB(A) |
| 4212 H | 119x119x38 | 12 VDC | 184,0 m3/h | 3400 min-1 | 5,30 W | 49 dB(A) |
| 4212 L | 119x119x38 | 12 VDC | 86,0 m3/h | 1600 min-1 | 1,20 W | 29 dB(A) |
| 4212 M | 119x119x38 | 12 VDC | 127,0 m3/h | 2350 min-1 | 2,20 W | 38 dB(A) |
| 4212 NGL | 119x119x38 | 12 VDC | 100,0 m3/h | 1700 min-1 | 1,40 W | 28 dB(A) |
| 4212 NGM | 119x119x38 | 12 VDC | 144,0 m3/h | 2450 min-1 | 3,10 W | 38 dB(A) |
| 4212 NGML | 119x119x38 | 12 VDC | 127,0 m3/h | 2150 min-1 | 2,30 W | 35 dB(A) |
| 4212 NGN | 119x119x38 | 12 VDC | 165,0 m3/h | 2750 min-1 | 4,30 W | 42 dB(A) |
| 4212 NH | 119x119x38 | 12 VDC | 180,0 m3/h | 3050 min-1 | 4,80 W | 45 dB(A) |
| 4212 NHH | 119x119x38 | 12 VDC | 205,0 m3/h | 3500 min-1 | 7,50 W | 49 dB(A) |
| 4212 NL | 119x119x38 | 12 VDC | 100,0 m3/h | 1700 min-1 | 1,10 W | 28 dB(A) |
| 4212 NM | 119x119x38 | 12 VDC | 144,0 m3/h | 2450 min-1 | 2,80 W | 38 dB(A) |
| 4212 NML | 119x119x38 | 12 VDC | 127,0 m3/h | 2150 min-1 | 1,90 W | 35 dB(A) |
| 4212 NN | 119x119x38 | 24 VDC | 165,0 m3/h | 2750 min-1 | 3,60 W | 42 dB(A) |
| 4214 G | 119x119x38 | 24 VDC | 165,0 m3/h | 3050 min-1 | 4,30 W | 45 dB(A) |
| 4214 H | 119x119x38 | 24 VDC | 184,0 m3/h | 3400 min-1 | 5,30 W | 49 dB(A) |
| 4214 L | 119x119x38 | 24 VDC | 86,0 m3/h | 1600 min-1 | 1,20 W | 29 dB(A) |
| 4214 NGL | 119x119x38 | 24 VDC | 100,0 m3/h | 1700 min-1 | 1,40 W | 28 dB(A) |
| 4214 NGM | 119x119x38 | 24 VDC | 144,0 m3/h | 2450 min-1 | 3,10 W | 38 dB(A) |
| 4214 NGML | 119x119x38 | 24 VDC | 127,0 m3/h | 2150 min-1 | 2,30 W | 35 dB(A) |
| 4214 NGN | 119x119x38 | 24 VDC | 165,0 m3/h | 2750 min-1 | 4,30 W | 42 dB(A) |
| 4214 NH | 119x119x38 | 24 VDC | 180,0 m3/h | 3050 min-1 | 4,80 W | 45 dB(A) |
| 4214 NHH | 119x119x38 | 24 VDC | 205,0 m3/h | 3500 min-1 | 7,50 W | 49 dB(A) |
| 4214 NL | 119x119x38 | 24 VDC | 100,0 m3/h | 1700 min-1 | 1,20 W | 28 dB(A) |
| 4214 NM | 119x119x38 | 24 VDC | 144,0 m3/h | 2450 min-1 | 2,60 W | 38 dB(A) |
| 4214 NML | 119x119x38 | 24 VDC | 127,0 m3/h | 2150 min-1 | 1,90 W | 35 dB(A) |
| 4214 NN | 119x119x38 | 24 VDC | 165,0 m3/h | 2750 min-1 | 3,60 W | 42 dB(A) |
| 4218 H | 119x119x38 | 48 VDC | 184,0 m3/h | 3400 min-1 | 5,60 W | 49 dB(A) |
| 4218 NGN | 119x119x38 | 48 VDC | 165,0 m3/h | 2750 min-1 | 4,00 W | 42 dB(A) |
| 4218 NH | 119x119x38 | 48 VDC | 180,0 m3/h | 3050 min-1 | 4,80 W | 45 dB(A) |
| 4218 NN | 119x119x38 | 48 VDC | 165,0 m3/h | 2750 min-1 | 3,60 W | 42 dB(A) |
| 4312 G | 119x119x32 | 12 VDC | 170,0 m3/h | 2800 min-1 | 5,00 W | 45 dB(A) |
| 4312 GL | 119x119x32 | 12 VDC | 95,0 m3/h | 1550 min-1 | 1,20 W | 30 dB(A) |
| 4312 GM | 119x119x32 | 12 VDC | 140,0 m3/h | 2300 min-1 | 2,60 W | 39 dB(A) |
| 4312 L | 119x119x32 | 12 VDC | 95,0 m3/h | 1550 min-1 | 1,20 W | 30 dB(A) |
| 4312 M | 119x119x32 | 12 VDC | 140,0 m3/h | 2300 min-1 | 2,60 W | 39 dB(A) |
| 4312 MV | 119x119x32 | 12 VDC | 140,0 m3/h | 2300 min-1 | 3,00 W | 39 dB(A) |
| 4312 NGL | 119x119x32 | 12 VDC | 93,0 m3/h | 1650 min-1 | 1,20 W | 27 dB(A) |
| 4312 NGM | 119x119x32 | 12 VDC | 137,0 m3/h | 2450 min-1 | 2,60 W | 37 dB(A) |
| 4312 NGN | 119x119x32 | 12 VDC | 166,0 m3/h | 3000 min-1 | 4,00 W | 43 dB(A) |
| 4312 NH | 119x119x32 | 12 VDC | 176,0 m3/h | 3150 min-1 | 4,50 W | 45 dB(A) |
| 4312 NHH | 119x119x32 | 12 VDC | 198,0 m3/h | 3600 min-1 | 6,50 W | 49 dB(A) |
| 4312 NL | 119x119x32 | 12 VDC | 93,0 m3/h | 1650 min-1 | 1,20 W | 27 dB(A) |
| 4312 NM | 119x119x32 | 12 VDC | 137,0 m3/h | 2450 min-1 | 2,60 W | 37 dB(A) |
| 4312 NN | 119x119x32 | 12 VDC | 166,0 m3/h | 3000 min-1 | 4,00 W | 43 dB(A) |
| 4312 V | 119x119x32 | 12 VDC | 170,0 m3/h | 2800 min-1 | 5,50 W | 45 dB(A) |
| 4312-143 | 119x119x32 | 12 VDC | 180,0 m3/h | 3000 min-1 | 5,80 W | 47 dB(A) |
| 4312-179 | 119x119x32 | 12 VDC | 204,0 m3/h | 3400 min-1 | 8,50 W | 51 dB(A) |
| 4314 G | 119x119x32 | 24 VDC | 170,0 m3/h | 2800 min-1 | 5,00 W | 45 dB(A) |
| 4314 L | 119x119x32 | 24 VDC | 95,0 m3/h | 1550 min-1 | 1,20 W | 30 dB(A) |
| 4314 M | 119x119x32 | 24 VDC | 140,0 m3/h | 2300 min-1 | 2,60 W | 39 dB(A) |
| 4314 NGL | 119x119x32 | 24 VDC | 93,0 m3/h | 1650 min-1 | 1,20 W | 27 dB(A) |
| 4314 NGM | 119x119x32 | 24 VDC | 137,0 m3/h | 2450 min-1 | 2,60 W | 37 dB(A) |
| 4314 NGN | 119x119x32 | 24 VDC | 166,0 m3/h | 3000 min-1 | 4,30 W | 43 dB(A) |
| 4314 NH | 119x119x32 | 24 VDC | 176,0 m3/h | 3150 min-1 | 4,50 W | 45 dB(A) |
| 4314 NHH | 119x119x32 | 24 VDC | 198,0 m3/h | 3600 min-1 | 6,00 W | 49 dB(A) |
| 4314 NL | 119x119x32 | 24 VDC | 93,0 m3/h | 1650 min-1 | 1,20 W | 27 dB(A) |
| 4314 NN | 119x119x32 | 24 VDC | 166,0 m3/h | 3000 min-1 | 4,30 W | 43 dB(A) |
| 4314 V | 119x119x32 | 24 VDC | 170,0 m3/h | 2800 min-1 | 5,40 W | 45 dB(A) |
| 4314-147 | 119x119x32 | 24 VDC | 180,0 m3/h | 3000 min-1 | 5,80 W | 47 dB(A) |
| 4314-180 | 119x119x32 | 24 VDC | 204,0 m3/h | 3400 min-1 | 9,50 W | 51 dB(A) |
| 4318 G | 119x119x32 | 48 VDC | 170,0 m3/h | 2800 min-1 | 5,00 W | 45 dB(A) |
| 4318 M | 119x119x32 | 48 VDC | 140,0 m3/h | 2300 min-1 | 3,50 W | 39 dB(A) |
| 4318 NGN | 119x119x32 | 48 VDC | 166,0 m3/h | 3000 min-1 | 4,10 W | 43 dB(A) |
| 4318 V | 119x119x32 | 48 VDC | 170,0 m3/h | 2800 min-1 | 5,40 W | 45 dB(A) |
| 4412 F | 119x119x25 | 12 VDC | 170,0 m3/h | 2900 min-1 | 5,30 W | 43 dB(A) |
| 4412 FG | 119x119x25 | 12 VDC | 170,0 m3/h | 2900 min-1 | 5,30 W | 43 dB(A) |
| 4412 FGL | 119x119x25 | 12 VDC | 94,0 m3/h | 1600 min-1 | 1,25 W | 26 dB(A) |
| 4412 FGM | 119x119x25 | 12 VDC | 140,0 m3/h | 2400 min-1 | 3,20 W | 38 dB(A) |
| 4412 FGML | 119x119x25 | 12 VDC | 114,0 m3/h | 1950 min-1 | 2,00 W | 32 dB(A) |
| 4412 FM | 119x119x25 | 12 VDC | 140,0 m3/h | 2400 min-1 | 3,20 W | 38 dB(A) |
| 4412 FML | 119x119x25 | 12 VDC | 114,0 m3/h | 1950 min-1 | 2,00 W | 32 dB(A) |
| 4414 F | 119x119x25 | 24 VDC | 170,0 m3/h | 2900 min-1 | 5,00 W | 43 dB(A) |
| 4414 FG | 119x119x25 | 24 VDC | 170,0 m3/h | 2900 min-1 | 5,00 W | 43 dB(A) |
| 4414 FL | 119x119x25 | 24 VDC | 94,0 m3/h | 1600 min-1 | 1,00 W | 26 dB(A) |
| 4414 FM | 119x119x25 | 24 VDC | 140,0 m3/h | 2400 min-1 | 3,20 W | 38 dB(A) |
| 4418 F | 119x119x25 | 48 VDC | 170,0 m3/h | 2900 min-1 | 5,50 W | 28 dB(A) |
| 4500 N | 119x119x38 | 115 VAC | 169,0 m3/h | 3000 min-1 | 15,00 W | 48 dB(A) |
| 4530 N | 119x119x38 | 115 VAC | 151,0 m3/h | 2700 min-1 | 16,00 W | 45 dB(A) |
| 4530 Z | 119x119x38 | 115 VAC | 120,0 m3/h | 2000 min-1 | 12,00 W | 32 dB(A) |
| 4536 Z | 119x119x38 | 115 VAC | 120,0 m3/h | 2000 min-1 | 12,00 W | 32 dB(A) |
| 4550 N | 119x119x38 | 230 VAC | 145,0 m3/h | 2550 min-1 | 16,50 W | 44 dB(A) |
| 4580 N | 119x119x38 | 230 VAC | 123,0 m3/h | 2350 min-1 | 18,00 W | 41 dB(A) |
| 4580 Z | 119x119x38 | 230 VAC | 115,0 m3/h | 1900 min-1 | 13,00 W | 30 dB(A) |
| 4586 Z | 119x119x38 | 230 VAC | 115,0 m3/h | 1900 min-1 | 13,00 W | 30 dB(A) |
| 4600 N | 119x119x38 | 115 VAC | 180,0 m3/h | 3100 min-1 | 18,00 W | 50 dB(A) |
| 4600 TA | Ø113x37 | 115 VAC | 147,0 m3/h | 2900 min-1 | 18,00 W | 43 dB(A) |
| 4600 TZ | Ø108x37 | 115 VAC | 140,0 m3/h | 2950 min-1 | 18,00 W | 45 dB(A) |
| 4600 Z | 119x119x38 | 115 VAC | 180,0 m3/h | 3100 min-1 | 18,00 W | 45 dB(A) |
| 4606 N | 119x119x38 | 115 VAC | 180,0 m3/h | 3100 min-1 | 18,00 W | 51 dB(A) |
| 4606 TA | Ø113x37 | 115 VAC | 147,0 m3/h | 2900 min-1 | 18,00 W | 44 dB(A) |
| 4606 TZ | Ø108x37 | 115 VAC | 140,0 m3/h | 2950 min-1 | 18,00 W | 45 dB(A) |
| 4606 Z | 119x119x38 | 115 VAC | 180,0 m3/h | 3100 min-1 | 18,00 W | 45 dB(A) |
| 4650 N | 119x119x38 | 230 VAC | 160,0 m3/h | 2650 min-1 | 19,00 W | 46 dB(A) |
| 4650 TA | Ø113x37 | 230 VAC | 138,0 m3/h | 2550 min-1 | 19,00 W | 41 dB(A) |
| 4650 TZ | Ø108x37 | 230 VAC | 125,0 m3/h | 2600 min-1 | 19,00 W | 42 dB(A) |
| 4650 Z | 119x119x38 | 230 VAC | 160,0 m3/h | 2650 min-1 | 19,00 W | 40 dB(A) |
| 4656 N | 119x119x38 | 230 VAC | 160,0 m3/h | 2650 min-1 | 19,00 W | 47 dB(A) |
| 4656 TA | Ø113x37 | 230 VAC | 138,0 m3/h | 2550 min-1 | 19,00 W | 42 dB(A) |
| 4656 TZ | Ø108x37 | 230 VAC | 125,0 m3/h | 2600 min-1 | 19,00 W | 42 dB(A) |
| 4656 Z | 119x119x38 | 230 VAC | 160,0 m3/h | 2650 min-1 | 19,00 W | 40 dB(A) |
| 4800 N | 119x119x38 | 115 VAC | 97,0 m3/h | 1750 min-1 | 9,00 W | 32 dB(A) |
| 4800 Z | 119x119x38 | 115 VAC | 105,0 m3/h | 1800 min-1 | 12,00 W | 28 dB(A) |
| 4806 Z | 119x119x38 | 115 VAC | 105,0 m3/h | 1800 min-1 | 12,00 W | 28 dB(A) |
| 4840 N | 119x119x38 | 115 VAC | 85,0 m3/h | 1650 min-1 | 10,00 W | 26 dB(A) |
| 4850 N | 119x119x38 | 230 VAC | 100,0 m3/h | 1800 min-1 | 10,00 W | 32 dB(A) |
| 4850 Z | 119x119x38 | 230 VAC | 100,0 m3/h | 1700 min-1 | 13,00 W | 26 dB(A) |
| 4856 Z | 119x119x38 | 230 VAC | 100,0 m3/h | 1700 min-1 | 13,00 W | 26 dB(A) |
| 4890 N | 119x119x38 | 230 VAC | 80,0 m3/h | 1550 min-1 | 11,00 W | 25 dB(A) |
| 5112 N | 135x135x38 | 12 VDC | 250,0 m3/h | 2900 min-1 | 9,50 W | 48 dB(A) |
| 5114 N | 135x135x38 | 24 VDC | 250,0 m3/h | 2900 min-1 | 9,50 W | 48 dB(A) |
| 5118 N | 135x135x38 | 48 VDC | 250,0 m3/h | 2900 min-1 | 9,50 W | 48 dB(A) |
| 5118 NL | 135x135x38 | 48 VDC | 122,0 m3/h | 1400 min-1 | 2,60 W | 28 dB(A) |
| 512 F | 50x50x15 | 12 VDC | 20,0 m3/h | 5000 min-1 | 1,00 W | 30 dB(A) |
| 514 F | 50x50x15 | 24 VDC | 20,0 m3/h | 5000 min-1 | 1,00 W | 30 dB(A) |
| 5212 NH | 127x127x38 | 12 VDC | 252,0 m3/h | 3650 min-1 | 9,80 W | 51 dB(A) |
| 5212 NM | 127x127x38 | 12 VDC | 187,0 m3/h | 2750 min-1 | 4,60 W | 43 dB(A) |
| 5212 NN | 127x127x38 | 12 VDC | 216,0 m3/h | 3150 min-1 | 6,00 W | 46 dB(A) |
| 5214 NH | 127x127x38 | 24 VDC | 252,0 m3/h | 3650 min-1 | 9,80 W | 51 dB(A) |
| 5214 NM | 127x127x38 | 24 VDC | 187,0 m3/h | 2750 min-1 | 4,60 W | 43 dB(A) |
| 5214 NN | 127x127x38 | 24 VDC | 216,0 m3/h | 3150 min-1 | 6,00 W | 46 dB(A) |
| 5218 NH | 127x127x38 | 48 VDC | 252,0 m3/h | 3650 min-1 | 10,00 W | 51 dB(A) |
| 5218 NM | 127x127x38 | 48 VDC | 187,0 m3/h | 2750 min-1 | 5,00 W | 43 dB(A) |
| 5218 NN | 127x127x38 | 48 VDC | 216,0 m3/h | 3150 min-1 | 6,50 W | 46 dB(A) |
| 5606 S | 135x135x38 | 115 VAC | 270,0 m3/h | 3100 min-1 | 26,00 W | 50 dB(A) |
| 5656 S | 135x135x38 | 230 VAC | 235,0 m3/h | 2700 min-1 | 30,00 W | 46 dB(A) |
| 6008 ES | Ø172x51 | 115 VAC | 440,0 m3/h | 3300 min-1 | 26,00 W | 58 dB(A) |
| 6028 ES | Ø172x51 | 115 VAC | 500,0 m3/h | 3300 min-1 | 29,00 W | 58 dB(A) |
| 605 F | 60x60x15 | 5 VDC | 29,0 m3/h | 4000 min-1 | 1,10 W | 27 dB(A) |
| 6058 ES | Ø172x51 | 230 VAC | 375,0 m3/h | 2800 min-1 | 24,00 W | 54 dB(A) |
| 6078 ES | Ø172x51 | 230 VAC | 420,0 m3/h | 2800 min-1 | 26,00 W | 54 dB(A) |
| 612 F | 60x60x15 | 12 VDC | 29,0 m3/h | 3900 min-1 | 1,00 W | 27 dB(A) |
| 612 FH | 60x60x15 | 12 VDC | 33,0 m3/h | 4500 min-1 | 1,40 W | 31 dB(A) |
| 612 FL | 60x60x15 | 12 VDC | 19,0 m3/h | 2650 min-1 | 0,40 W | 16 dB(A) |
| 612 NGLE | 60x60x25 | 12 VDC | 21,0 m3/h | 2500 min-1 | 0,60 W | 16 dB(A) |
| 612 NGME | 60x60x25 | 12 VDC | 35,0 m3/h | 4100 min-1 | 1,20 W | 28 dB(A) |
| 612 NGMI | 60x60x25 | 12 VDC | 35,0 m3/h | 4100 min-1 | 1,70 W | 28 dB(A) |
| 612 NGMLE | 60x60x25 | 12 VDC | 25,0 m3/h | 3000 min-1 | 0,70 W | 19 dB(A) |
| 612 NGNI | 60x60x25 | 12 VDC | 41,0 m3/h | 5100 min-1 | 2,40 W | 35 dB(A) |
| 612 NH | 60x60x25 | 12 VDC | 46,0 m3/h | 5600 min-1 | 2,00 W | 37 dB(A) |
| 612 NHH-118 | 60x60x25 | 12 VDC | 56,0 m3/h | 6800 min-1 | 2,90 W | 41 dB(A) |
| 612 NLE | 60x60x25 | 12 VDC | 21,0 m3/h | 2500 min-1 | 0,40 W | 16 dB(A) |
| 612 NME | 60x60x25 | 12 VDC | 35,0 m3/h | 4100 min-1 | 0,80 W | 28 dB(A) |
| 612 NMI | 60x60x25 | 12 VDC | 35,0 m3/h | 4100 min-1 | 1,40 W | 28 dB(A) |
| 612 NMLE | 60x60x25 | 12 VDC | 25,0 m3/h | 3000 min-1 | 0,40 W | 19 dB(A) |
| 612 NN | 60x60x25 | 12 VDC | 42,0 m3/h | 5100 min-1 | 1,60 W | 35 dB(A) |
| 612 NNI | 60x60x25 | 12 VDC | 41,0 m3/h | 5100 min-1 | 1,50 W | 35 dB(A) |
| 614 F | 60x60x15 | 24 VDC | 29,0 m3/h | 3900 min-1 | 1,10 W | 27 dB(A) |
| 614 NGL | 60x60x25 | 24 VDC | 21,0 m3/h | 2500 min-1 | 1,00 W | 16 dB(A) |
| 614 NGM | 60x60x25 | 24 VDC | 35,0 m3/h | 4100 min-1 | 1,70 W | 28 dB(A) |
| 614 NGML | 60x60x25 | 24 VDC | 25,0 m3/h | 3000 min-1 | 1,20 W | 19 dB(A) |
| 614 NH | 60x60x25 | 24 VDC | 46,0 m3/h | 5600 min-1 | 2,10 W | 37 dB(A) |
| 614 NHH | 60x60x25 | 24 VDC | 56,0 m3/h | 6850 min-1 | 3,00 W | 41 dB(A) |
| 614 NHH-119 | 60x60x25 | 24 VDC | 56,0 m3/h | 6850 min-1 | 3,00 W | 41 dB(A) |
| 614 NL | 60x60x25 | 24 VDC | 21,0 m3/h | 2500 min-1 | 0,90 W | 16 dB(A) |
| 614 NM | 60x60x25 | 24 VDC | 35,0 m3/h | 4100 min-1 | 1,40 W | 28 dB(A) |
| 614 NML | 60x60x25 | 24 VDC | 25,0 m3/h | 3000 min-1 | 1,00 W | 19 dB(A) |
| 614 NN | 60x60x25 | 24 VDC | 42,0 m3/h | 5100 min-1 | 1,80 W | 35 dB(A) |
| 618 NM | 60x60x25 | 48 VDC | 35,0 m3/h | 4100 min-1 | 1,40 W | 28 dB(A) |
| 618 NN | 60x60x25 | 48 VDC | 42,0 m3/h | 5100 min-1 | 2,10 W | 35 dB(A) |
| 6212 NM | Ø172x55 | 12 VDC | 350,0 m3/h | 2850 min-1 | 12,00 W | 50 dB(A) |
| 622 H | 60x60x25 | 12 VDC | 46,0 m3/h | 6850 min-1 | 2,30 W | 39 dB(A) |
| 622 HH | 60x60x25 | 12 VDC | 56,0 m3/h | 8200 min-1 | 3,50 W | 43 dB(A) |
| 622 L | 60x60x25 | 12 VDC | 21,0 m3/h | 3200 min-1 | 0,50 W | 22 dB(A) |
| 622 M | 60x60x25 | 12 VDC | 30,0 m3/h | 4550 min-1 | 1,00 W | 29 dB(A) |
| 622 N | 60x60x25 | 12 VDC | 40,0 m3/h | 6100 min-1 | 1,90 W | 36 dB(A) |
| 6224 N | Ø172x55 | 24 VDC | 410,0 m3/h | 3400 min-1 | 18,00 W | 55 dB(A) |
| 6224 NH | Ø172x55 | 24 VDC | 480,0 m3/h | 4000 min-1 | 26,00 W | 61 dB(A) |
| 6224 NM | Ø172x55 | 24 VDC | 350,0 m3/h | 2850 min-1 | 12,00 W | 50 dB(A) |
| 6224 NT | Ø172x55 | 24 VDC | 410,0 m3/h | 3400 min-1 | 18,00 W | 55 dB(A) |
| 6224 NTD | Ø172x51 | 24 VDC | 600,0 m3/h | 5100 min-1 | 50,00 W | 65 dB(A) |
| 624 H | 60x60x25 | 24 VDC | 46,0 m3/h | 6850 min-1 | 2,30 W | 39 dB(A) |
| 624 HH | 60x60x25 | 24 VDC | 56,0 m3/h | 8200 min-1 | 3,60 W | 43 dB(A) |
| 624 L | 60x60x25 | 24 VDC | 21,0 m3/h | 3200 min-1 | 1,00 W | 22 dB(A) |
| 624 M | 60x60x25 | 24 VDC | 30,0 m3/h | 4550 min-1 | 1,50 W | 29 dB(A) |
| 624 N | 60x60x25 | 24 VDC | 40,0 m3/h | 6100 min-1 | 2,20 W | 36 dB(A) |
| 6248 N | Ø172x55 | 48 VDC | 410,0 m3/h | 3400 min-1 | 17,00 W | 55 dB(A) |
| 6248 NH | Ø172x55 | 48 VDC | 480,0 m3/h | 4000 min-1 | 26,00 W | 61 dB(A) |
| 6248 NL | Ø172x55 | 48 VDC | 205,0 m3/h | 1700 min-1 | 4,00 W | 35 dB(A) |
| 6248 NM | Ø172x55 | 48 VDC | 350,0 m3/h | 2850 min-1 | 11,50 W | 50 dB(A) |
| 6248 NT | Ø172x55 | 48 VDC | 410,0 m3/h | 3400 min-1 | 17,00 W | 55 dB(A) |
| 6248 NTD | Ø172x51 | 48 VDC | 600,0 m3/h | 5100 min-1 | 50,00 W | 65 dB(A) |
| 6412 M | 172x150x51 | 12 VDC | 350,0 m3/h | 2850 min-1 | 12,00 W | 52 dB(A) |
| 6424 H | 172x150x51 | 24 VDC | 480,0 m3/h | 4000 min-1 | 26,00 W | 63 dB(A) |
| 6424 M | 172x150x51 | 24 VDC | 350,0 m3/h | 2850 min-1 | 12,00 W | 52 dB(A) |
| 6424 T | 172x150x51 | 24 VDC | 410,0 m3/h | 3400 min-1 | 18,00 W | 57 dB(A) |
| 6448 H | 172x150x51 | 48 VDC | 480,0 m3/h | 4000 min-1 | 26,00 W | 63 dB(A) |
| 6448 M | 172x150x51 | 48 VDC | 350,0 m3/h | 2850 min-1 | 11,50 W | 52 dB(A) |
| 6448 T | 172x150x51 | 48 VDC | 410,0 m3/h | 3400 min-1 | 17,00 W | 57 dB(A) |
| 7006 ES | 150x172x38 | 115 VAC | 390,0 m3/h | 3300 min-1 | 24,00 W | 57 dB(A) |
| 7056 ES | 150x172x38 | 230 VAC | 330,0 m3/h | 2800 min-1 | 29,00 W | 52 dB(A) |
| 7112 N | Ø150x38 | 12 VDC | 360,0 m3/h | 2850 min-1 | 12,00 W | 55 dB(A) |
| 7114 N | Ø150x38 | 24 VDC | 360,0 m3/h | 2850 min-1 | 12,00 W | 55 dB(A) |
| 7114 NH | Ø150x38 | 24 VDC | 420,0 m3/h | 3350 min-1 | 19,00 W | 59 dB(A) |
| 7118 N | Ø150x38 | 48 VDC | 360,0 m3/h | 2850 min-1 | 12,00 W | 55 dB(A) |
| 712 F | 70x70x15 | 12 VDC | 44,0 m3/h | 5300 min-1 | 1,70 W | 38 dB(A) |
| 712 F/2L | 70x70x15 | 12 VDC | 28,0 m3/h | 3300 min-1 | 0,60 W | 25 dB(A) |
| 712 F/2M | 70x70x15 | 12 VDC | 36,0 m3/h | 4300 min-1 | 1,10 W | 32 dB(A) |
| 714 F | 70x70x15 | 24 VDC | 44,0 m3/h | 5300 min-1 | 1,50 W | 38 dB(A) |
| 7212 N | Ø150x55 | 12 VDC | 360,0 m3/h | 3050 min-1 | 12,00 W | 50 dB(A) |
| 7214 N | Ø150x55 | 24 VDC | 360,0 m3/h | 3050 min-1 | 12,00 W | 50 dB(A) |
| 7218 N | Ø150x55 | 48 VDC | 360,0 m3/h | 3050 min-1 | 12,00 W | 50 dB(A) |
| 7400 ES | Ø150x55 | 115 VAC | 445,0 m3/h | 3050 min-1 | 46,00 W | 60 dB(A) |
| 7450 ES | Ø150x55 | 230 VAC | 390,0 m3/h | 2700 min-1 | 47,00 W | 58 dB(A) |
| 7805 ES | Ø150x55 | 115 VAC | 380,0 m3/h | 3250 min-1 | 38,00 W | 52 dB(A) |
| 7806 ES | Ø150x55 | 115 VAC | 380,0 m3/h | 3250 min-1 | 38,00 W | 52 dB(A) |
| 7855 ES | Ø150x55 | 230 VAC | 325,0 m3/h | 2800 min-1 | 45,00 W | 48 dB(A) |
| 7856 ES | Ø150x55 | 230 VAC | 325,0 m3/h | 2800 min-1 | 45,00 W | 48 dB(A) |
| 8305 G | 80x80x32 | 5 VDC | 48,0 m3/h | 3050 min-1 | 2,20 W | 34 dB(A) |
| 8312 G | 80x80x32 | 12 VDC | 54,0 m3/h | 3300 min-1 | 2,50 W | 36 dB(A) |
| 8312 GL | 80x80x32 | 12 VDC | 32,0 m3/h | 2000 min-1 | 1,00 W | 24 dB(A) |
| 8312 GM | 80x80x32 | 12 VDC | 48,0 m3/h | 3000 min-1 | 1,80 W | 34 dB(A) |
| 8312 H | 80x80x32 | 12 VDC | 80,0 m3/h | 5000 min-1 | 5,50 W | 48 dB(A) |
| 8312 HL | 80x80x32 | 12 VDC | 67,0 m3/h | 4200 min-1 | 4,00 W | 43 dB(A) |
| 8312 L | 80x80x32 | 12 VDC | 32,0 m3/h | 2000 min-1 | 1,00 W | 24 dB(A) |
| 8312 M | 80x80x32 | 12 VDC | 48,0 m3/h | 3000 min-1 | 1,80 W | 34 dB(A) |
| 8314 G | 80x80x32 | 24 VDC | 54,0 m3/h | 3300 min-1 | 2,50 W | 36 dB(A) |
| 8314 H | 80x80x32 | 24 VDC | 80,0 m3/h | 5000 min-1 | 6,00 W | 48 dB(A) |
| 8314 HL | 80x80x32 | 24 VDC | 67,0 m3/h | 4200 min-1 | 4,30 W | 43 dB(A) |
| 8314 L | 80x80x32 | 24 VDC | 32,0 m3/h | 2000 min-1 | 1,00 W | 24 dB(A) |
| 8314 M | 80x80x32 | 24 VDC | 48,0 m3/h | 3000 min-1 | 2,10 W | 34 dB(A) |
| 8318 H | 80x80x32 | 48 VDC | 80,0 m3/h | 5000 min-1 | 5,80 W | 48 dB(A) |
| 8318 HL | 80x80x32 | 48 VDC | 67,0 m3/h | 4200 min-1 | 4,30 W | 43 dB(A) |
| 8412 N | 80x80x25 | 12 VDC | 69,0 m3/h | 3100 min-1 | 2,00 W | 32 dB(A) |
| 8412 NG | 80x80x25 | 12 VDC | 69,0 m3/h | 3100 min-1 | 2,00 W | 32 dB(A) |
| 8412 NGLE | 80x80x25 | 12 VDC | 33,0 m3/h | 1500 min-1 | 0,50 W | 12 dB(A) |
| 8412 NGLV | 80x80x25 | 12 VDC | 33,0 m3/h | 1500 min-1 | 1,10 W | 12 dB(A) |
| 8412 NGME | 80x80x25 | 12 VDC | 58,0 m3/h | 2600 min-1 | 1,40 W | 26 dB(A) |
| 8412 NGMLE | 80x80x25 | 12 VDC | 45,0 m3/h | 2050 min-1 | 0,90 W | 19 dB(A) |
| 8412 NGMLV | 80x80x25 | 12 VDC | 45,0 m3/h | 2050 min-1 | 1,50 W | 19 dB(A) |
| 8412 NGMV | 80x80x25 | 12 VDC | 58,0 m3/h | 2600 min-1 | 2,00 W | 26 dB(A) |
| 8412 NH | 80x80x25 | 12 VDC | 79,0 m3/h | 3600 min-1 | 2,20 W | 37 dB(A) |
| 8412 NH-217 | 80x80x25 | 12 VDC | 79,0 m3/h | 3600 min-1 | 2,40 W | 37 dB(A) |
| 8412 NLE | 80x80x25 | 12 VDC | 33,0 m3/h | 1500 min-1 | 0,30 W | 17 dB(A) |
| 8412 NME | 80x80x25 | 12 VDC | 58,0 m3/h | 2600 min-1 | 1,00 W | 27 dB(A) |
| 8412 NMLE | 80x80x25 | 12 VDC | 45,0 m3/h | 2050 min-1 | 0,60 W | 21 dB(A) |
| 8414 N | 80x80x25 | 24 VDC | 69,0 m3/h | 3100 min-1 | 2,00 W | 32 dB(A) |
| 8414 NG | 80x80x25 | 24 VDC | 69,0 m3/h | 3100 min-1 | 2,00 W | 32 dB(A) |
| 8414 NGL | 80x80x25 | 24 VDC | 33,0 m3/h | 1500 min-1 | 0,70 W | 12 dB(A) |
| 8414 NGM | 80x80x25 | 24 VDC | 58,0 m3/h | 2600 min-1 | 1,40 W | 26 dB(A) |
| 8414 NGML | 80x80x25 | 24 VDC | 45,0 m3/h | 2050 min-1 | 1,10 W | 19 dB(A) |
| 8414 NH | 80x80x25 | 24 VDC | 79,0 m3/h | 3600 min-1 | 2,40 W | 37 dB(A) |
| 8414 NH-221 | 80x80x25 | 24 VDC | 79,0 m3/h | 3600 min-1 | 3,20 W | 37 dB(A) |
| 8414 NL | 80x80x25 | 24 VDC | 33,0 m3/h | 1500 min-1 | 0,70 W | 17 dB(A) |
| 8414 NM | 80x80x25 | 24 VDC | 58,0 m3/h | 2600 min-1 | 1,40 W | 27 dB(A) |
| 8414 NML | 80x80x25 | 24 VDC | 45,0 m3/h | 2050 min-1 | 1,10 W | 21 dB(A) |
| 8500 A | 80x80x38 | 115 VAC | 57,0 m3/h | 3200 min-1 | 11,00 W | 41 dB(A) |
| 8500 N | 80x80x38 | 115 VAC | 61,0 m3/h | 3200 min-1 | 11,00 W | 34 dB(A) |
| 8500 TA | Ø76x37 | 115 VAC | 45,0 m3/h | 3150 min-1 | 11,00 W | 30 dB(A) |
| 8500 TV | Ø76x37 | 115 VAC | 47,0 m3/h | 3150 min-1 | 11,00 W | 32 dB(A) |
| 8506 A | 80x80x38 | 115 VAC | 57,0 m3/h | 3300 min-1 | 11,00 W | 42 dB(A) |
| 8506 N | 80x80x38 | 115 VAC | 61,0 m3/h | 3300 min-1 | 11,00 W | 35 dB(A) |
| 8506 TA | Ø76x37 | 115 VAC | 45,0 m3/h | 3250 min-1 | 11,00 W | 31 dB(A) |
| 8506 TV | Ø76x37 | 115 VAC | 47,0 m3/h | 3250 min-1 | 11,00 W | 33 dB(A) |
| 8550 A | 80x80x38 | 230 VAC | 48,0 m3/h | 2700 min-1 | 12,00 W | 36 dB(A) |
| 8550 N | 80x80x38 | 230 VAC | 50,0 m3/h | 2700 min-1 | 12,00 W | 30 dB(A) |
| 8550 TA | Ø76x37 | 230 VAC | 38,0 m3/h | 2650 min-1 | 12,00 W | 25 dB(A) |
| 8550 TV | Ø76x37 | 230 VAC | 40,0 m3/h | 2650 min-1 | 12,00 W | 27 dB(A) |
| 8556 A | 80x80x38 | 230 VAC | 48,0 m3/h | 2800 min-1 | 12,00 W | 37 dB(A) |
| 8556 N | 80x80x38 | 230 VAC | 50,0 m3/h | 2800 min-1 | 12,00 W | 31 dB(A) |
| 8556 TA | Ø76x37 | 230 VAC | 38,0 m3/h | 2750 min-1 | 12,00 W | 26 dB(A) |
| 8556 TV | Ø76x37 | 230 VAC | 40,0 m3/h | 2750 min-1 | 12,00 W | 28 dB(A) |
| 8800 A | 80x80x38 | 115 VAC | 45,0 m3/h | 2500 min-1 | 11,00 W | 34 dB(A) |
| 8800 N | 80x80x38 | 115 VAC | 47,0 m3/h | 2500 min-1 | 11,00 W | 28 dB(A) |
| 8800 TA | Ø76x37 | 115 VAC | 34,0 m3/h | 2450 min-1 | 11,00 W | 23 dB(A) |
| 8800 TV | Ø76x37 | 115 VAC | 36,0 m3/h | 2450 min-1 | 11,00 W | 24 dB(A) |
| 8830 A | 80x80x38 | 115 VAC | 34,0 m3/h | 1950 min-1 | 8,00 W | 29 dB(A) |
| 8830 N | 80x80x38 | 115 VAC | 36,0 m3/h | 1950 min-1 | 8,00 W | 21 dB(A) |
| 8830 TA | Ø76x37 | 115 VAC | 26,0 m3/h | 1850 min-1 | 8,00 W | 18 dB(A) |
| 8830 TV | Ø76x37 | 115 VAC | 27,0 m3/h | 1850 min-1 | 8,00 W | 18 dB(A) |
| 8850 A | 80x80x38 | 230 VAC | 36,0 m3/h | 2150 min-1 | 12,50 W | 31 dB(A) |
| 8850 N | 80x80x38 | 230 VAC | 37,0 m3/h | 2150 min-1 | 12,50 W | 24 dB(A) |
| 8850 TA | Ø76x37 | 230 VAC | 30,0 m3/h | 2100 min-1 | 12,00 W | 19 dB(A) |
| 8850 TV | Ø76x37 | 230 VAC | 31,0 m3/h | 2100 min-1 | 12,00 W | 20 dB(A) |
| 8880 A | 80x80x38 | 230 VAC | 29,0 m3/h | 1750 min-1 | 9,00 W | 26 dB(A) |
| 8880 N | 80x80x38 | 230 VAC | 30,0 m3/h | 1750 min-1 | 9,00 W | 18 dB(A) |
| 8880 TA | Ø76x37 | 230 VAC | 23,0 m3/h | 1650 min-1 | 9,00 W | 15 dB(A) |
| 8880 TV | Ø76x37 | 230 VAC | 24,0 m3/h | 1650 min-1 | 9,00 W | 15 dB(A) |
| 9906 L | 119x119x25 | 115 VAC | 100,0 m3/h | 2100 min-1 | 8,00 W | 34 dB(A) |
| 9906 M | 119x119x25 | 115 VAC | 111,0 m3/h | 2450 min-1 | 8,00 W | 37 dB(A) |
| 9956 L | 119x119x25 | 230 VAC | 84,0 m3/h | 1850 min-1 | 9,50 W | 29 dB(A) |
| 9956 M | 119x119x25 | 230 VAC | 104,0 m3/h | 2250 min-1 | 10,00 W | 35 dB(A) |
| W1G200HH0152 | 225x225x80 | 48 VDC | 1005,0 m3/h | 2750 min-1 | 45,00 W | 60 dB(A) |
| W1G200HH7752 | 225x225x80 | 24 VDC | 1090,0 m3/h | 2950 min-1 | 55,00 W | 60 dB(A) |
| W1G250HH3752 | 280x280x80 | 24 VDC | 1920,0 m3/h | 2750 min-1 | 105,00 W | 70 dB(A) |
| W1G250HH6752 | 280x280x80 | 48 VDC | 1920,0 m3/h | 2750 min-1 | 105,00 W | 70 dB(A) |
| W2E142BB0101 | 150x172x38 | 230 VAC | 330,0 m3/h | 2800 min-1 | 29,00 W | 52 dB(A) |
| W2E142BB0101 | 150x172x38 | 230 VAC | 390,0 m3/h | 3300 min-1 | 28,00 W | 57 dB(A) |
| W2E142BB0501 | 150x172x38 | 115 VAC | 330,0 m3/h | 2800 min-1 | 25,00 W | 52 dB(A) |
| W2E142BB0501 | 150x172x38 | 115 VAC | 390,0 m3/h | 3300 min-1 | 24,00 W | 57 dB(A) |
| W2E143AA0901 | Ø171.5x51 | 230 VAC | 375,0 m3/h | 2800 min-1 | 24,00 W | 55 dB(A) |
| W2E143AA0901 | Ø171.5x51 | 230 VAC | 440,0 m3/h | 3300 min-1 | 26,00 W | 60 dB(A) |
| W2E143AA1501 | Ø171.5x51 | 115 VAC | 375,0 m3/h | 2800 min-1 | 24,00 W | 55 dB(A) |
| W2E143AA1501 | Ø171.5x51 | 115 VAC | 440,0 m3/h | 3300 min-1 | 26,00 W | 60 dB(A) |
| W2E143AB0901 | Ø171.5x51 | 230 VAC | 420,0 m3/h | 2800 min-1 | 26,00 W | 54 dB(A) |
| W2E143AB0901 | Ø171.5x51 | 230 VAC | 500,0 m3/h | 3300 min-1 | 29,00 W | 58 dB(A) |
| W2E143AB1501 | Ø171.5x51 | 115 VAC | 420,0 m3/h | 2800 min-1 | 26,00 W | 54 dB(A) |
| W2E143AB1501 | Ø171.5x51 | 115 VAC | 500,0 m3/h | 3300 min-1 | 29,00 W | 58 dB(A) |
| W2E200HK3801 | 225x225x80 | 230 VAC | 925,0 m3/h | 2550 min-1 | 64,00 W | 59 dB(A) |
| W2E200HK3801 | 225x225x80 | 230 VAC | 1030,0 m3/h | 2800 min-1 | 80,00 W | 61 dB(A) |
| W2E200HK8601 | 225x225x80 | 115 VAC | 925,0 m3/h | 2550 min-1 | 64,00 W | 59 dB(A) |
| W2E200HK8601 | 225x225x80 | 115 VAC | 1030,0 m3/h | 2800 min-1 | 80,00 W | 61 dB(A) |
| W2E250HL0601 | 280x280x80 | 230 VAC | 1830,0 m3/h | 2500 min-1 | 110,00 W | 69 dB(A) |
| W2E250HL0601 | 280x280x80 | 230 VAC | 1910,0 m3/h | 2630 min-1 | 150,00 W | 70 dB(A) |
| W2S130AA0301 | Ø150x55 | 230 VAC | 325,0 m3/h | 2800 min-1 | 45,00 W | 49 dB(A) |
| W2S130AA0301 | Ø150x55 | 230 VAC | 380,0 m3/h | 3250 min-1 | 39,00 W | 53 dB(A) |
| W2S130AA2501 | Ø150x55 | 115 VAC | 325,0 m3/h | 2800 min-1 | 41,00 W | 49 dB(A) |
| W2S130AA2501 | Ø150x55 | 115 VAC | 380,0 m3/h | 3250 min-1 | 38,00 W | 53 dB(A) |
| W2S130BM0301 | Ø150x55 | 230 VAC | 380,0 m3/h | 2700 min-1 | 47,00 W | 60 dB(A) |
| W2S130BM0301 | Ø150x55 | 230 VAC | 425,0 m3/h | 3050 min-1 | 46,00 W | 62 dB(A) |
| W2S130BM1501 | Ø150x55 | 230 VAC | 380,0 m3/h | 2700 min-1 | 47,00 W | 60 dB(A) |
| W2S130BM1501 | Ø150x55 | 230 VAC | 425,0 m3/h | 3050 min-1 | 46,00 W | 62 dB(A) |
| W4S200HK0401 | 225x225x80 | 230 VAC | 450,0 m3/h | 1370 min-1 | 30,00 W | 40 dB(A) |
| W4S200HK0401 | 225x225x80 | 230 VAC | 525,0 m3/h | 1590 min-1 | 26,00 W | 44 dB(A) |
