LCD12864，单色12864点阵LCD液晶模块
请选择 型号/数量
商品详情
以下是部分12864LCD模块的型号和尺寸资料：
|
产品型号
|
点阵数(列*行)
|
外形尺寸 (mm)
|
视域尺寸(mm)
|
控制器
|
说明
|
| HTM12232A | 122*32 | 84.0*44.0 | 60.0*18.0 | SED1520 |
|
| HTM12232Z | 122*32 | 84.0*44.0 | 60.0*18.0 | ST7920 | 中文字库，支持串口和并口 |
| HTM12864-18 | 128*64 | 93.0*70.0 | 71.7*38.8 | NT7534 |
COG MODE |
| HTM12864-18P | 128*64 | 93.0*70.0 | 71.7*38.8 | NT7534 | COG MODE |
| HTM12864-19 | 128*64 | 45.0*42.0 | 36.0*23.5 | ST7565P |
COG，串口 |
| HTM12864-20 | 128*64 | 104.0*56.0 | 65.4*37.8 | S6B0724 |
COG MODE |
| HTM12864-23 | 128*64 | 54.0*50.0 | 45.2*27.0 | ST7565P |
|
| HTM12864-27 | 128*64 | 93.0*70.0 | 65.5*38.0 | S6B0724/NT7534 |
|
| HTM12864-6 | 128*64 | 78.0*70.0 | 62.0*44.0 | T6963C |
|
| HTM12864-7 | 128*64 | 95.0*55.7 | 65.0*38.0 | S6B0724 |
COG 串口 |
| HTM12864-8 | 128*64 | 90.0*59.0 | 65.0*38.0 | S6B0724 |
COG 串口 |
| HTM12864-8B | 128*64 | 90.0*59.0 | 65.0*38.0 | S6B0724 |
COG 并口 |
| HTM12864-8G | 128*64 | 80.0*70.0 | 65.0*38.0 | S6B0724 |
|
| HTM12864A | 128*64 | 113.0*65.0 | 73.4*38.8 | KS0108 |
|
| HTM12864B | 128*64 | 93.0*70.0 | 71.7*39.0 | KS0108 |
|
| HTM12864C1 | 128*64 | 48.6*37.9 | 36.0*23.5 | ST7565 |
COG 串/并 |
| HTM12864C2 | 128*64 | 40.6*32.2 | 37.0*23.3 | ST7565 |
COG 串/并 |
| HTM12864D | 128*64 | 78.0*70.0 | 62.0*44.0 | KS0108 |
|
| HTM12864F | 128*64 | 54.0*50.0 | 43.5*29.0 | KS0108 |
|
| HTM12864Z | 128*64 | 93.0*70.0 | 71.7*39.0 | ST7920 | 带中文字库 |
