ICO雷达MR-1200系列雷达
请选择 型号/数量
商品详情
Easy-to-see large 12.1-inch TFT display assists your safe navigation
Three types of scanner units
MR-1200RII : 36NM range, 4kW radome scanner
MR-1200TII : 48NM range, 4kW open array scanner
MR-1200TIII : 72NM range, 6kW open array scanner
12.1-inch large TFT display (600×800 dots)
Slim depth (119.2mm) and light weight (4.3kg)
Simplified ATA (Automatic Traking Aid) function
CPA, TCPA and alarm zone function
English and Korean indication
Head-up, North-up, Course-up & True motion*
* External bearing, speed and position data required. Depends on display mode.
General
MR-1200RII | MR-1200TII | MR-1200TIII | |
|---|---|---|---|
| Minimum range | 25m (when measurement range is 1/8 NM) | ||
| Maximum range | 36NM | 48NM | 72NM |
| Power supply requirement | 10.2–42V DC | ||
| Power consumption (at zero wind velocity) | 60W (approx.) | 70W (approx.) | 80W (approx.) |
Display
MR-1200RII | MR-1200TII | MR-1200TIII | |
|---|---|---|---|
| Display type | 12.1-inch TFT LCD | ||
| Resolution | 600×800 dots | ||
| Usable temperature range | –15°C to +55°C + 5°F to +131°F | ||
| Dimensions (W×H×D) (projections not included) | 300×323×119.2 mm | ||
| Weight (approx.) | 4.3kg | ||
Scanner
MR-1200RII | MR-1200TII | MR-1200TIII | ||
|---|---|---|---|---|
| Type | 2ft (60cm) radome scanner | 4ft (120cm) open array scanner | ||
| Peak output power | 4kW | 6kW | ||
| Rotation speed | 24/36/48rpm typ. (#02 Version) 24/36rpm typ. (#07 Version) | 24/36/48rpm typ. (#12 Version) 24/36rpm typ. (#17 version) | 22/24/36/48rpm typ. (#22 Version) 22/24/36rpm typ. (#27 Version) | |
| Beamwidth | Horizontal | 4° typ. | 2° typ. | |
| Vertical | 22° typ. | 25° typ. | ||
| Side lobe | ?18dB typ. (#02 Version) ?22dB typ. (#07 Version) | ?24dB typ. | ||
| Intermediate frequency | 60MHz | |||
| Transmission frequency | 9410MHz ±30MHz | |||
| Usable temperature range | ?25°C to +70°C ?13°F to +158°F | |||
| Dimensions (projections not included) | 607(?)×243(H) mm (#02 Version) 640(W)×256(H)×640(D) (mm) (#07 Version) | 1200×381×399 mm | ||
| Weight (approx.) | 8kg (without cable) | 17kg (without cable) | ||
All stated specifications are subject to change without notice or obligation.
CABLES
 OPC-1077A20m (65.6ft)SYSTEM CABLE | OPC-1078A30m (98.4ft)SYSTEM CABLE |
