70W笔记本电源，70W家用笔记本适配器

￥26

规格：70W

包装：精美吸卡包装

品牌：jinhotai

商品详情

70W笔记本电源，70W家用笔记本适配器尽在深圳市锦鸿泰科技有限公司

本款电源是笔记本多功能电源适配器,,

宽电压输入,,,7个电压输出,,,配有8个端子,,能适合大部分笔记本的需要,,

是一款家用笔记本电源

Model:SCAC2004

1.General Description:

This model is an universal switching-mode power supply for laptop and LCD Monitor, operation at input AC 100V to 240V 47-63Hz , Output:DC 7 voltages:12V/15V/16V/18V/19V/20V/24V , output power 70 Watt max, with protection functions:overload protection, Short Circuit Protection, power supply by mains supply. With 8PCS tip connection to suit to almost Laptops , Select output voltage to suit to laptop and LCD monitor make sure the polarity of tips connect correct before use.

2.Electric Characteristics:

No.	Item	Specification
1.	Rated Input Voltage (50-60Hz)	AC120V OR AC230V
1.	Vibration Input Voltage Range (47-63Hz)	AC100V-240V
2.	Input Rated Current	1.0AMP
2.	Input Power	100VA
3.	Output power(max)	70W
3.	Efficiency	>80%(TYP)
4.	Output Voltage:DC 12V/15/16V/18V/19V/20V/24V(-0.2/+0.8V NO LOAD)	DC12V-24V
5	Output voltage:DC 12V/15V/16V/18V/19V/20V/22V(-0.9/+0.8Vrating load) Output current:12V/15V 4A MAX, 16V/18V/19V/20V 3.5A MAX, 24V2.9A MAX	DC12V-24V 4.0AMP(max)
6.	Overload protection	YES
7.	Short Circuit Protection	YES
8.	Line Regulation	+/-5%
9.	Load Regulation	+/-5%
