Rubadue UL AWM 1517

￥2

规格： UL AWM 1517

品牌：Rubadue

商品详情

UL AWM STYLE 1517

Product Information

Temperature Rating:

105°C

Wire Category:

Basic (1 layer)

Insulation:

ETFE

Size Range:

20 AWG - 32 AWG

Compliances:

RoHS Compliant

UL/IEC 60950-1 (Ed. 2), am1 Annex U.

CSA AWM C22.2 No. 210.2 - M90

License No. LL84686-1

File No. E78621

UL AWM Style 1517

Voltage Rating:

NSV

Insulation Information

Insulation Type:

Fluoropolymer

Thermal:

Continuous Operating Temperature, 150°C

UL Flammability Rating:

V-0

Dielectric Constant:

2.6

Tensile Strength (psi):

6500

Elongation(%):

150-300

Abrasion Resistance:

Excellent

Bondability:

Poor

UV Resistance:

Excellent

Chemical Resistance:

Excellent

Water Resistance:

Excellent

Underground Resistance:

Excellent

Long Term Stability:

Excellent

BARE CORE WIRE SPECIFICATIONS:

AWG	Min. Dia.	Nom. Dia.	Max. Dia.	Min. Res.*	Nom. Res.	Max. Res.
20	0.0317	0.0320	0.0330	0.0975	0.1053	0.1108
21	0.0282	0.0285	0.0294	0.1229	0.1328	0.1400
22	0.0250	0.0253	0.0261	0.1559	0.1685	0.1781
23	0.0224	0.0226	0.0233	0.1956	0.2112	0.2219
24	0.0199	0.0201	0.0207	0.2478	0.2669	0.2811
25	0.0177	0.0179	0.0184	0.3137	0.3366	0.3554
26	0.0157	0.0159	0.0164	0.3948	0.4266	0.4517
27	0.0141	0.0142	0.0146	0.4982	0.5349	0.5600
28	0.0125	0.0126	0.0130	0.6283	0.6793	0.7125
29	0.0112	0.0113	0.0116	0.7892	0.8446	0.8875
30	0.0099	0.0100	0.0103	1.0009	1.0785	1.1359
31	0.0088	0.0089	0.0092	1.2546	1.3616	1.4376
32	0.0079	0.0080	0.0083	1.5414	1.6852	1.7838

*ASTM B33 sets no standard for minimum resistance. This is only an indicator to investigate other aspects such as tin-thickness and tin coverage.

Conductor:

Tin Plated Copper, Solid or Stranded (ASTM B-33/ASTM B-286)

Bare Copper and other conductors available

ETFE is a Fluoropolymer compound with excellent electrical properties, heat resistance, chemical resistance, and abrasion resistance. Commonly used in winding wires, UL AWM wires, and medical applications.

INSULATED WIRE INFORMATION:

Part Number	AWG	Inches	MM	Inches	MM	Weight LB/KFT
S20A01TX-6.5	20	0.0320	0.813	0.0450	1.143	3.67
S21A01TX-6.5	21	0.0285	0.724	0.0415	1.054	2.99
S22A01TX-6.5	22	0.0253	0.643	0.0383	0.973	2.42
S23A01TX-6.5	23	0.0226	0.574	0.0356	0.904	1.99
S24A01TX-6.5	24	0.0201	0.511	0.0331	0.841	1.62
S25A01TX-6.5	25	0.0179	0.455	0.0309	0.785	1.34
S26A01TX-6.5	26	0.0159	0.404	0.0289	0.734	1.10
S27A01TX-6.5	27	0.0142	0.361	0.0272	0.691	0.92
S28A01TX-6.5	28	0.0126	0.320	0.0256	0.650	0.77
S29A01TX-6.5	29	0.0113	0.287	0.0243	0.617	0.65
S30A01TX-6.5	30	0.0100	0.254	0.0230	0.584	0.55
S31A01TX-6.5	31	0.0089	0.226	0.0219	0.556	0.47
S32A01TX-6.5	32	0.0080	0.203	0.0210	0.533	0.41
